Terraform Associate Notes

Mục lục

What?

Exam objectives

No	Objective
1	Understand Infrastructure as Code (IaC) concepts
1a	Explain what IaC is
1b	Describe advantages of IaC patterns
2	Understand Terraform's purpose (vs other IaC)
2a	Explain multi-cloud and provider-agnostic benefits
2b	Explain the benefits of state
3	Understand Terraform basics
3a	Handle Terraform and provider installation and versioning
3b	Describe plug-in based architecture
3c	Demonstrate using multiple providers
3d	Describe how Terraform finds and fetches providers
3e	Explain when to use and not use provisioners and when to use local-exec or remote-exec
4	Use the Terraform CLI (outside of core workflow)
4a	Given a scenario: choose when to use terraform fmt to format code
4b	Given a scenario: choose when to use terraform taint to taint Terraform resources
4c	Given a scenario: choose when to use terraform import to import existing infrastructure into your Terraform state
4d	Given a scenario: choose when to use terraform workspace to create workspaces
4e	Given a scenario: choose when to use terraform state to view Terraform state
4f	Given a scenario: choose when to enable verbose logging and what the outcome/value is
5	Interact with Terraform modules
5a	Contrast module source options
5b	Interact with module inputs and outputs
5c	Describe variable scope within modules/child modules
5d	Discover modules from the public Terraform Module Registry
5e	Defining module version
6	Navigate Terraform workflow
6a	Describe Terraform workflow ( Write -> Plan -> Create )
6b	Initialize a Terraform working directory (terraform init)
6c	Validate a Terraform configuration (terraform validate)
6d	Generate and review an execution plan for Terraform (terraform plan)
6e	Execute changes to infrastructure with Terraform (terraform apply)
6f	Destroy Terraform managed infrastructure (terraform destroy)
7	Implement and maintain state
7a	Describe default local backend
7b	Outline state locking
7c	Handle backend authentication methods
7d	Describe remote state storage mechanisms and supported standard backends
7e	Describe effect of Terraform refresh on state
7f	Describe backend block in configuration and best practices for partial configurations
7g	Understand secret management in state files
8	Read, generate, and modify configuration
8a	Demonstrate use of variables and outputs
8b	Describe secure secret injection best practice
8c	Understand the use of collection and structural types
8d	Create and differentiate resource and data configuration
8e	Use resource addressing and resource parameters to connect resources together
8f	Use Terraform built-in functions to write configuration
8g	Configure resource using a dynamic block
8h	Describe built-in dependency management (order of execution based)
9	Understand Terraform Cloud and Enterprise capabilities
9a	Describe the benefits of Sentinel, registry, and workspaces
9b	Differentiate OSS and Terraform Cloud workspaces
9c	Summarize features of Terraform Cloud

Question Types

https://developer.hashicorp.com/terraform/tutorials/certification/associate-questions

True or False
Multiple Choice
Multiple Answer
Text Match

Why?

Benefits

Verify skills
Expand skills
Enterprise features
Solidify fundamentals

IAC and its benefits

No more clicks
Enable DevOps (version control, collaboration)
Declarative infrastructure
Speed, Cost, Reduced Risk
Cloud Agnostic

Workflow

write -> collaboration
plan -> review
apply -> deploy

Terraform commands, concepts

Commands

terraform init
# download ancillary components and set up the backend (state file,...)

terraform plan
# show a plan of execution/deployment, allowing you to review and authenticate credentials

terraform apply
# deploy the instructions, and statements in the code, update the state files

terraform destroy
# destroy all resources in the state file. It would be best if you backed up before you destroyed anything

Resource addressing

# Provider
provider "aws" {
    region = "us-east-1"
}

provider "google" {
    credentials = file("credentials.json")
    project = "my-gcp-project"
    region = "us-west-1"
}

# Resource
# reserved keyword + resource provided by Terraform provider + Use-provided arbitrary resource name
resource "aws_instance" "web" {
    ami = "ami-abc12312"
    instance_type = "t2.micro"
    # resource config arguments
}

# Resource Address
aws_instance.web

# Data source
# A data source block = fetching and tracking details of an existing resource
# A resource block = creates a resource from scratch.
# reserved keyword + resource provided by Terraform provider + Use-provided arbitrary resource name
data "aws_instance" "my-vm" {
    instance_id = "i-123123123"
    # data source arguments
}
# Data source address
data.aws_instance.my-vm

Tf executes code in files with the .tf extension
TF looks for providers in TF provider registry
Task: Create a VM on AWS using TF

main.tf

provider "aws" {
    region = "us-east-1"
}

resource "aws_instance" "vm" {
    ami = "ami-0c4e4b4eb2e11d1d4"
    subnet_id = "subnet-08d180d74f2ef9dfc"
    instance_type = "t3.micro"
}

Installing TF and TF providers

TF

TF providers

Abstracting integration with the API control layer
Look at the TF registry
Providers are plugins
TF can use custom providers
tf init installs providers
Best practice: specific version of provider -> better version control, won't break your code

provider "azurerm" {
    version = "2.20.0"
    features {}
}

provider "aws" {
    version = "3.7.0"
    region = "us-east-1"
}

TF state

Concept

Resource tracking
- Keep tabs on what has been deployed
- Critical to TF operations
terraform.tfstate = mapping configuration with deployed resource
can be stored remotely
Never lose your tf state file or let it in the wrong hand

TF Variables and Outputs

Variables

# reserved keyword + user-provided variable name
variable "my-var" {
    description = "My test variable"
    type = string
    value = "Hello"
    validation {
        condition = length(var.my_var) > 4
        error_message = "The string must be more than 4 characters"
    }
    # set it to true if you don't want it printed out in the tf execution, false by default
    sensitive = true
}

# you can define a var like this
# however, if not defined in OS env or CLI import otherwise, it will end up in err
variable "my-var" {}

# referencing a var:
var.my_var

# Base types: string, number, bool
# Complex types: list, set, map, object, tuple
# string
variable "image_id" {
    type = string
    default = "hello"
}
# list of string
variable "az_names" {
    type = list(string)
    default = ["us-east-1"]
}
# list of object
variable "docker_ports" {
    type = list(object({
        internal = number
        external = number
        protocol = string
    }))
    default = [
        {
            internal = 8300
            external = 8300
            protocol = "tcp"
        }
    ]
}

terraform.tfvars will be picked up by default

Outputs

# reserved keyword + user-provided var name
output "instance_ip" {
    description = "VM's private  IP"
    values = aws_instance.my-vm.private_ip
}

Output vars values are shown on the shell after running tf apply
Think as return values to track after a success the tf deployment

TF Provisioners

Bootstrapping custom scripts, commands, or actions
Can be run locally or remotely
Individual resources can have their own "provisioner"
2 types:
- creation-time
- destroy-time
Best practice:
In the case of provisioners, HashiCorp recommends using them sparingly and only when the underlying vendors, such as AWS, do not already provide a built-in mechanism for bootstrapping via custom commands or scripts. For example, AWS allows passing scripts through user data in EC2 virtual machines. So if there's a better inherently available method for a resource, Hashicorp recommends using that.
TF cannot track changes to provisioners in state files
Only when you want to invoke actions not covered by TF declarative model.
Expected provisioner return non-zero return code; otherwise, the resource will be trained and re-create again on the subsequent execution
Sample code

resource  "null_resource" "dummy_resource" {
    provisioner "local-exec" {
        command = "echo '0' > status.txt"
    }

    provisioner "local-exec" {
        when = destroy
        command = "echo '1' > status.txt"
    }
}

resource "aws_instance" "ec2-vm" {
    ami = "ami"
    instance_type = "t3.micro"
    subnet_id = "subnet_id"
    provisioner "local-exec" {
        command = "aws ec2 wait instance-status-ok --region us-east-1 --instance-ids ${self.id}"
    }
}
# And so Hashicorp has provided the self-object can access any attribute available to the resource the provisioner is attached to.

Resources: https://developer.hashicorp.com/terraform/language/resources/provisioners/syntax

TF State Commands

maps real-world resource -> tf config
by default, it saves in the terraform.tfstate file
tf refresh state file before any modification
resource dependency metadata also included

State commands

manipulate and read the tf state file
scenario:
- advanced state management
- manually remove a resource
- list out tracked resources and their details

# list all resources tracked by state file
tf state list
# delete a resource from the state file tracking
tf state rm
# show details of a resource
tf state show

Local and remote state storage

Local state storage
- save locally on your system by default
Remote state storage
- S3, Google Storage
- Allows sharing of state files between teams
- State files can use remote access to limit the access
allow locking state so parallel execution doesn't coincide
enable sharing output values with other tf config or code
Demo: Persisting TF state in AWS S3

aws --profile vntechies s3api create-bucket --bucket vntechies-tf-samples

main.tf

provider "docker" {}

resource "docker_image" "nginx-image" {
  name = "nginx"
}

resource "docker_container" "nginx" {
  image = docker_image.nginx-image.latest
  name  = "nginx"
  ports {
    internal = 80
    external = var.external_port
    protocol = "tcp"
  }
}

output "url" {
  description = "Browser URL for container site"
  value       = join(":", ["http://localhost", tostring(var.external_port)])
}

backend.tf

terraform {
  required_providers {
    docker = {
      source = "kreuzwerker/docker"
    }
  }
  required_version = ">=1.0"
  backend "s3" {
    profile = "vntechies"
    region  = "us-east-1"
    key     = "terraform.tfstate"
    bucket  = "vntechies-tf-sample"
  }
}

variable.tf

variable "external_port" {
  type    = number
  default = 8080
  validation {
    condition     = can(regex("8080|80", var.external_port))
    error_message = "Port value can only be 8080 or 80."
  }
}

aws --profile vntechies s3 ls s3://vntechies-tf-samples/

TF Modules

container for multiple resources that are used together
tf config has at least one module called root
can be downloaded or referenced from:
- tf public registry
- private registry
- local system
can take inputs and provide outputs

# reserved keyword + module name
module "my-vpc-module" {
    source = "./modules/vpc" # module source (mandatory)
    version = "0.0.5" # module version
    region = var.region # input params for module
}
# allowed params: count, for_each, providers, depends_on

Interact with module inputs/outputs

module "my-vpc-module" {
    source = "./modules/vpc"
    server-name = var.server-name # refers to vars
}
output "ip_address" {
    value = aws_instance.private_ip
}
# refers to module out put
module.my_vpc-module.subnet_id

Lab: building and testing basic tf module

alias tf=terraform
mkdir -p terraform/module/vpc
touch terraform/module/vpc/main.tf terraform/module/vpc/variables.tf terraform/module/vpc/outputs.tf terraform/main.tf
cd terraform/module/vpc/

/module/vpc/variables.tf

variable "region" {
  type    = string
  default = "us-east-1"
}

/module/vpc/main.tf

provider "aws" {
  region = var.region
}

resource "aws_vpc" "this" {
  cidr_block = "10.0.0.0/16"
}

resource "aws_subnet" "this" {
  vpc_id     = aws_vpc.this.id
  cidr_block = "10.0.1.0/24"
}

data "aws_ssm_parameter" "this" {
  name = "/aws/service/ami-amazon-linux-latest/amzn2-ami-hvm-x86_64-gp2"
}

/module/vpc/outputs.tf

output "subnet_id" {
  value = aws_subnet.this.id
}

output "ami_id" {
  value = data.aws_ssm_parameter.this.value
}

variable "main_region" {
  type    = string
  default = "us-east-1"
}

provider "aws" {
  region = var.main_region
}

module "vpc" {
  source = "./module/vpc"
}

resource "aws_instance" "my-instance" {
  ami           = module.vpc.ami_id
  subnet_id     = module.vpc.subnet_id
  instance_type = "t3.micro"
}

output "PrivateIP" {
  description = "Private IP of EC2 instance"
  value       = aws_instance.my-instance.private_ip
}

TF built-in functions

pre-packaged with functions to transform and combine values
user-defined functions are not allowed, only built-in
general syntax: function_name(arg1, arg2,...)
Built-in functions

join("-", ["terraform", var.project-name])
# file, max, flatten

Resources:
- https://developer.hashicorp.com/terraform/language/functions
tf console

tf console

> max(12,3,4,24,14)
24
> timestamp()
"2022-10-29T00:54:07Z"
> join("-",["test","11232"])
"test-11232"
> contains(["test",1,2,3,3], 2)
true
> contains(["test",1,2,3,3], 5)
false

TF Type Constraints

Primitive
- number
- string
- bool
Complex
- list
- tuple
- map
- object
Collections
- list(type)
- map(type)
- set(type)
Structural
- object(type)
- tuple(type)
- set(type)
Dynamic Type
- any
- the best effort to decide the type

TF Dynamic blocks

construct repeatable nested configuration blocks
support block types:
- resource
- data
- provider
- provisioner

variable "rules" {
  default = [
    {
      port        = 80
      protocol    = "tcp"
      cidr_blocks = ["0.0.0.0/0"]
    },
    {
      port        = 22
      protocol    = "tcp"
      cidr_blocks = ["1.2.3.4/32"]
    }
  ]

}

resource "aws_security_group" "my-sg" {
  name   = "my-aws-sg"
  vpc_id = aws_vpc.my-vpc.id
  dynamic "ingress" {
    for_each = var.rules
    content {
      from_port  = ingress.values["port"]
      to_port    = ingress.values["port"]
      protocol   = ingress.values["protocol"]
      cidr_block = ingress.values["cirds"]
    }
  }
}

Lab: Using Terraform Dynamic Blocks and Built-in Functions to Deploy to AWS

alias tf=terraform
touch main.tf variables.tf outputs.tf script.sh

variables.tf

variable "rules" {
  type = list(object({
    port        = number
    protocol    = string
    cidr_blocks = list(string)
  }))

  default = [{
    cidr_blocks = ["0.0.0.0/0"]
    port        = 80
    protocol    = "tcp"
    }, {
    cidr_blocks = ["0.0.0.0/0"]
    port        = 22
    protocol    = "tcp"
    }, {
    cidr_blocks = ["6.7.8.9/32"]
    port        = 3689
    protocol    = "tcp"
  }]
}

main.tf

provider "aws" {
  region = "us-east-1"
}

data "aws_ssm_parameter" "ami_id" {
  name = "/aws/service/ami-amazon-linux-latest/amzn2-ami-hvm-x86_64-gp2"
}

module "vpc" {
  source = "terraform-aws-modules/vpc/aws"

  name = "my-vpc"
  cidr = "10.0.0.0/16"

  azs            = ["us-east-1a"]
  public_subnets = ["10.0.1.0/24"]
}

resource "aws_security_group" "my-sg" {
  vpc_id = module.vpc.vpc_id
  name   = join("_", ["sg", module.vpc.vpc_id])
  dynamic "ingress" {
    for_each = var.rules
    content {
      from_port   = ingress.value["port"]
      to_port     = ingress.value["port"]
      protocol    = ingress.value["protocol"]
      cidr_blocks = ingress.value["cidr_blocks"]
    }
  }
  egress {
    cidr_blocks = ["0.0.0.0/0"]
    from_port   = 0
    protocol    = "-1"
    to_port     = 0
  }
  tags = {
    "Name" = "Terraform-Dynamic-SG"
  }
}

resource "aws_instance" "my-instance" {
  ami             = data.aws_ssm_parameter.ami_id.value
  subnet_id       = module.vpc.public_subnets[0]
  instance_type   = "t3.micro"
  security_groups = [aws_security_group.my-sg.id]
  user_data       = fileexists("script.sh") ? file("script.sh") : null
}

outputs.tf

output "Web-Server-URL" {
  description = "Web server URL"
  value       = join("", ["http://", aws_instance.my-instance.public_ip])
}

output "Time-Date" {
  description = "Date/time of execution"
  value       = timestamp()
}

script.sh

#!/bin/bash
sudo yum -y install httpd
sudo systemctl start httpd && sudo systemctl enable httpd

TF fmt, taint, import

TF fmt

Format for code readability
Safe to run anytime
Helps in keeping code consistent

tf fmt

TF taint

taint a resource, forcing it to be destroyed and recreated
modifies the state file case the recreation workflows
may cause others to be modified

tf taint RESOURCE_ADD

When
- to cause provisioners to run
- replace misbehaving resources
- mimic side effects of recreation not modeled by any attributes of the resource

TF import

map existing resources to tf using an ID
ID depends on underlying vendors
import the same resource to multiple tf resources can cause unknown behavior and is not recommende
d

tf import Resource_address ID

When:
- need to work with existing resources
- not allowed to create new resources
- not in control of the creation process

TF config blocks

config block for controlling tf own behavior
only allows constant, named resources, and variables are not allowed

terraform {
  required_version = ">=1.0"
  required_providers {
    aws = ">=3.0"
}

TF workspaces (CLI)

alternate state files within the same working dir
tf starts with default workspace, cannot be deleted

# create a workspace
tf workspace new WORKSPACE_NAME
# select a workspace
tf workspace select WORKSPACE_NAME

Scenario:
- Test changes using a parallel, distinct copy of infra
- can be modeled against branches in version control
Meant to share resources and help enable collaboration
Access to workspace ${terraform.workspace}
Examples:

resource "aws_instance" "example" {
  count = terraform.workspace == "default" ? 5 : 1
}

resource "aws_s3_bucket" "bucket" {
  bucket = "bucket-${terraform.workspace}"
  acl = "private"
}

Demo: Workspace

touch main.tf network.tf
tf workspace new test

network.tf

resource "aws_vpc" "vpc_master" {
  cidr_block = "10.0.0.0/16"
  tags = {
    Name = "${terraform.workspace}-vpc"
  }
}

data "aws_availability_zones" "azs" {
  state = "available"
}

resource "aws_subnet" "subnet" {
  availability_zone = element(data.aws_availability_zones.azs.names, 0)
  vpc_id            = aws_vpc.vpc_master.id
  cidr_block        = "10.0.1.0/24"

  tags = {
    Name = "${terraform.workspace}-subnet"
  }
}

resource "aws_security_group" "sg" {
  name        = "${terraform.workspace}-sg"
  description = "Allow TCP 22"
  vpc_id      = aws_vpc.vpc_master.id
  ingress {
    description = "Allow 22 from public IP"
    from_port   = 22
    to_port     = 22
    protocol    = "tcp"
    cidr_blocks = ["0.0.0.0/0"]
  }
  egress {
    from_port   = 0
    to_port     = 0
    protocol    = "tcp"
    cidr_blocks = ["0.0.0.0/0"]
  }
  tags = {
    Name = "${terraform.workspace}-sg"
  }
}

main.tf

provider "aws" {
  region = "us-east-1"
}

data "aws_ssm_parameter" "ami_id" {
  name = "/aws/service/ami-amazon-linux-latest/amzn2-ami-hvm-x86_64-gp2"
}

resource "aws_instance" "ec2-vm" {
  ami                         = data.aws_ssm_parameter.ami_id.value
  instance_type               = "t3.micro"
  associate_public_ip_address = true
  vpc_security_group_ids      = [aws_security_group.sg.id]
  subnet_id                   = aws_subnet.subnet.id
  tags = {
    Name = "${terraform.workspace}-ec2"
  }
}

Debugging TF

TF_LOG -> stderr
levels: TRACE, DEBUG, INFO, WARN, ERROR
TF_LOG_PATH

export TF_LOG=TRACE
export TF_LOG_PATH=./terraform.log

TF Enterprise

Sentinel

Enforces policies on your code
Has its own policy language
designed to be approached by a non-programmer
Benefits
- Sandboxing
- Codification
- Version control
- Testing and automation
Use cases
- For enforcing CIS standards
- Checking to make sure only t3.micro instance types are used
- Ensure SG don't allow traffic on port 22

import "tfplan"
main = rule {
  all tfplan.resouces.aws_instance as _, instances {
    all instances as _, f {
      (length(r.applied.tags) else 0) > 0
    }
  }
}

Best Practice: Vault Provider

Secret management software
dynamically provisions credentials and rotates them
encrypt sensitive data in transit and reset, provide fine-grained access to secrets using ACLs
inject secrets using Vault Provider
Benefits:
- Don't need long-lived credentials
- Inject secrets to TF deployment at runtime
- Fine-grained ACLs for access to temp credentials

TF Registry, TF Cloud workspaces

TF Registry

The repository of publicly available TF providers and modules
you can publish and share your modules and collaborate with others

TF Cloud workspaces

dir hosted in TF cloud
store old versions of state files by default
maintain a record of all execution
all TF commands executed on "managed" TF Cloud VMs

TF OSS workspaces and TF Cloud

Component	Workspace	Cloud workspace
Terraform Configuration	On disk	In linked version control repository or periodically uploaded via API/CLI
Variable Values	As .tfvars files, as CLI arguments, or in shell environment	In workspace (in TF Cloud)
State	On disk or in remote backend	In workspace (in TF Cloud)
Credentials and Secrets	In shell environment or entered at prompts	In workspace (in TF Cloud), stored as sensitive variables
